BROADCAST LIVE VIDEO ANYWHERE OVER PUBLIC INTERNET

SHIFT Live Distribution World Map

SHIFT delivers an outstanding performance, highest quality (SD, HD, UHD) and ease of control of live signal distribution over the public internet and closed networks: encrypted, loss-less with low-latency.

As a result of the combination of industry-proven streaming protocols with SRT video transport technology, powered by years of experience in broadcasting and distribution, the SHIFT platform maximizes your efficiency in delivering content in a cost-efficient and scalable way.

DEPLOY ANYWHERE

Software & Infrastructure in your own hands without any limits
white diagonal small rotated.png
Key Benefits >

KEY BENEFITS

Live Video Distribution Management

  • SRT distribution over unreliable networks

  • End-to-end AES 128/256 encryption

  • Loss-less distribution with ARQ packet recovery

  • Low latency live signal distribution

Hiscale SHIFT Edge Details
Use Cases >

HYBRID SIGNAL DISTRIBUTION

Manage, Control & Monitor your Hybrid Live Video Streams

SHIFT redundancy hybrid live signal distribution

For all incoming source signals, SHIFT is the main gateway. It receives live signals from sports events and uses the SRT protocol to stream the content to two FLICS transcoding instances that record defined ABR profiles to be used to publish content on the VOD platform of the customer.

As the availability of the VOD assets is of high value to the customer, the entire recording and publishing workflow runs on-premise and in the cloud as a backup. SHIFT delivers live feeds simultaneously to both transcoder instances and is used for monitoring the source signals.

LIVE PRODUCTION IN THE CLOUD

Manage & Route Live Signals in Public Cloud Environments
SHIFT cloud live production

This use case describes a live production scenario, where the content is produced in a studio, and the live production is done in the cloud, remotely controlled by operators working from another location.

​

All live camera signals are sent to a SHIFT cloud installation over the public internet using the SRT protocol.

SHIFT takes the incoming sources and sends them as TS/UDP stream to the live cloud mixer application that is accessed and controlled remotely. The live output of the mixer (TS/UDP) received by SHIFT is forwarded to an on-premise decoder via SRT over the public internet to view the live output on a control monitor.

Technical Details >
white diagonal small rotated mirrored.pn
shift arrow1.png

LEARN MORE ABOUT SHIFT

shift arrow2.png

A variety of different customer profiles may utilize SHIFT features and benefits when they need to transfer, receive, or deliver live video. By making use of future-ready technology on standard IT platforms and networks, they become faster and more efficient

than before, setting up their global or local live distribution.

​

Continue reading to learn more about the features and included protocols available with SHIFT.

Deployment & Operation
  • Stand-alone Software solutions based on the latest Docker technology

  • Easy deployment on standard server hardware, virtual environments, and cloud machines

  • User-friendly configuration of streams through HTML5 web interface

  • End-to-end 128/256 bit AES encryption

  • Low latency video streaming

  • Loss-less transfer, protecting against jitter, packet-loss, and bandwidth fluctuation

  • Highly compatible with other SRT solutions

  • Signal routing to desired output ethernet interfaces

Monitoring & Alarming
  • Real-time data for enhanced monitoring

  • Flexible alarm configuration available for all input & output parameters

  • API notification interface

  • Live services monitoring with grid and list view

  • State-of-the-art logfile handling

  • Live server metrics dashboard

Formats & Interfaces
  • Input/Output Protocols

  • TS over UDP

  • TS over TCP

  • TS over RTP

  • RTMP

  • SRT

  • ZIXI

  • Easy integration via well documented RESTful API

  • Full remote management capabilities

... and so much more!

There are limitless use cases for SHIFT to be used as your signal distribution system, central live signal routing solution to a protocol switching hub. If you are looking for a particular feature,  get in touch with us to learn more!​

Features are subject to change.
